Green Motion DC EV Charger 50-150KW

Green Motion EV chargers

Experience ultra-fast and efficient electric vehicle (EV) charging with the Eaton Green Motion DC EV Charger. Engineered to meet the demands of modern EV drivers, this advanced DC charger combines high power output, intelligent features, and robust design to provide an unparalleled charging experience for both commercial and public use. Upgrade your charging infrastructure with the Eaton Green Motion DC EV Charger for a superior, reliable charging solution.

Width: 32.8"

Depth: 30.7"

Height: 71.8"

Weight: 688

SKU:

Width: 32.8"

Depth: 30.7"

Height: 71.8"

Weight: 688

Eaton Green Motion DC EV Charger: Fast, Reliable, and Smart Charging for Electric Vehicles
Experience the future of electric vehicle charging with the Eaton Green Motion DC EV Charger. Designed to deliver high-power DC charging, this charger significantly reduces charging times for all-electric and plug-in hybrid vehicles, making it perfect for commercial and public charging applications. With advanced energy management and connectivity features, the Green Motion DC EV Charger ensures efficient and cost-effective operation while providing a seamless charging experience.
- Support current and future EVs with 200–1000 Vdc charging
- Small footprint at 150 kW
- Up to 300 A cables
- Supports OCPP 1.6J (Open Charge Point Protocol)
- Ethernet and 4G cellular connectivity
- Future ISO 15118 “plug and charge” support
- With built-in RFID card reader
- Plug and charge (ISO 15118)
- Static load management integrated
- Suitable for dynamic load management
- Frequency rating 60 Hz
- Degree of protection IP54; NEMA 3R
- Cord length 7.5 mm
- One vehicle connectors (type 1 CCS)
- Power per charging point - max 50 kW
- Three Phase
- Small footprint
- Mission Critical Service Support - OCPP 1.6J
- Ethernet or 4G communication
- ISO 15118 Plug and Charge
PPI-eaton-green-motion-dc-fast-charger-datasheet-td154002en
PPI-Installation Options

EATON GREEN MOTION 50–150 kW DC FAST CHARGERS

Description	Catalog number	Maximum power rating (kW)
Private fleet charging	single cable models
DC150 CCS1 300A	GMDC150-CCS	50
DC50 CCS1 125A	GMDC50-CCS	150
Private fleet charging	dual cable models
DC50 CCS1x2 125A	GMDC50-CCSX2	50
DC75 CCS1x2 200A	GMDC75-CCSX2	75
DC100 CCS1x2 300A	GMDC100-CCSX2	100
DC125 CCS1x2 300A	GMDC125-CCSX2	125
DC150 CCS1x2 300A	GMDC150-CCSX2	150

Description
Eaton Green Motion DC EV Charger: Fast, Reliable, and Smart Charging for Electric Vehicles
Experience the future of electric vehicle charging with the Eaton Green Motion DC EV Charger. Designed to deliver high-power DC charging, this charger significantly reduces charging times for all-electric and plug-in hybrid vehicles, making it perfect for commercial and public charging applications. With advanced energy management and connectivity features, the Green Motion DC EV Charger ensures efficient and cost-effective operation while providing a seamless charging experience.

Key Features
- Support current and future EVs with 200–1000 Vdc charging
- Small footprint at 150 kW
- Up to 300 A cables
- Supports OCPP 1.6J (Open Charge Point Protocol)
- Ethernet and 4G cellular connectivity
- Future ISO 15118 “plug and charge” support
- With built-in RFID card reader
- Plug and charge (ISO 15118)
- Static load management integrated
- Suitable for dynamic load management
- Frequency rating 60 Hz
- Degree of protection IP54; NEMA 3R
- Cord length 7.5 mm
- One vehicle connectors (type 1 CCS)
- Power per charging point - max 50 kW
- Three Phase
- Small footprint
- Mission Critical Service Support - OCPP 1.6J
- Ethernet or 4G communication
- ISO 15118 Plug and Charge
